2GIG-TILT100-345

345S Wireless Tilt Sensor

The 2GIG TILT100-345 sensor is designed to monitor the tilt of assets like garage doors, mailboxes, pet doors, or storm cellar doors.

Coming Soon

Description

The 2GIG TILT100-345 sensor is designed to monitor the tilt of assets like garage doors, mailboxes, pet doors, or storm cellar doors. It communicates with the control panel using a 345 MHz frequency, transmitting a signal when titled beyond 45 degrees and sending a restore signal once it returns to a less than 45-degree angle. The sensor includes a tamper switch that alerts if the cover is removed and features low battery monitoring, sending a report when the battery level is low.

Features

• Monitors tilt status

• Case tamper and battery supervision 2GIG 345MHz compatible

• Double-sided tape and mounting screws included

• Battery life up to 10 years

• On-off switchable encryption

Specifications

  • Transmitter Frequency: 345MHz
  • Compatibility: 2GIG Panels
  • Code Outputs: Alarm; Alarm Restore; Supervisory; Tamper; Tamper Restore; Low Battery
  • Supervisory Interval: 70 Minutes
  • External Input: Accepts NC or NO dry contact devices
  • Housing Material: ABS Plastic
  • Operating Temperature: 2° to 120°F (-16 to 49°C)
  • Relative Humidity: 15% to 85%, Non-condensing
  • Batteries (Installed): One 3V CR2450 Lithium Battery
  • Battery Life: Up to 10-years
  • Certification: ETL, FCC, Industry Canada

Downloads

2GIG TILT100-345 Datasheet
